CG6

系列参数机型CG6R(Z)175AR(Z)180水冷单缸柴油机动力类型/Power type单缸,水冷,四冲程,卧式/Single cylinder,Water-cooled,Four stoke,Horizontal type燃烧室型式/Combustion chamber type涡流(直喷)/Whirling (Direct injection)缸径(mm)/Cylinder Bore767580行程(mm)/Piston stroke6580排量(L)/Displacement0.295&nbs

联系电话
立即咨询
系列参数机型
CG6R(Z)175AR(Z)180
水冷单缸柴油机动力类型/Power type单缸,水冷,四冲程,卧式/Single cylinder,Water-cooled,Four stoke,Horizontal type
燃烧室型式/Combustion chamber type涡流(直喷)/Whirling (Direct injection)
缸径(mm)/Cylinder Bore767580
行程(mm)/Piston stroke6580
排量(L)/Displacement0.295 0.353 0.402
压缩比/Compression ratio2220(18)
额定转速(rpm)/Rated speed30002600
额定功率(kw)/Rated power3.84.415.15
额定功率(hp)/Rated power5.17 6.00 7.00
最大功率( KW)/Max power4.18 4.85 5.67
最大功率 (HP)/Max power5.68 6.60 7.70
最大扭矩(N.m)/Max torque16.10 18.63 21.75
最大扭矩点转速(r/min)/Speed at Max torque point225019501950
标定点燃油耗(g/kw.h)/Fuel consumption303280.2(263.8)278.8(258.2)
起动方式/Start mode手摇或电起动/Hand start or eletric start
燃油牌号/Fuel number柴油:0#(夏)-10(冬)Fuel:0#(Summer),-10(Winter)
机油牌号/Oil numberSAE10W30(CD级以上)
外形尺寸(长*宽*高)(mm)/Overall dimension 486×255×352589×341×463625×341×463
净重(kg)Net weight436875
