系列参数机型机型CG173FCG178FCG182FCG186FACG188FBCG192FCG195FCGF1100F风冷单缸柴油机动力类型/Power type单缸，风冷，四冲程，立式/Single cylinder,Water-cooled,Four stoke,Vertical type燃烧室型式/Combustion chamber type直喷/Direct injection缸径(mm)/Cylinder Bore73788286889295100行程(mm)/Piston stroke59626
| 系列 | 参数 | 机型 | 机型 | ||||||
| CG173F | CG178F | CG182F | CG186FA | CG188FB | CG192F | CG195F | CGF1100F | ||
| 风冷单缸柴油机 | 动力类型/Power type | 单缸，风冷，四冲程，立式/Single cylinder,Water-cooled,Four stoke,Vertical type | |||||||
| 燃烧室型式/Combustion chamber type | 直喷/Direct injection | ||||||||
| 缸径(mm)/Cylinder Bore | 73 | 78 | 82 | 86 | 88 | 92 | 95 | 100 | |
| 行程(mm)/Piston stroke | 59 | 62 | 65 | 72 | 75 | 75 | 75 | 85 | |
| 排量(L)/Displacement | 0.247 | 0.296 | 0.343 | 0.418 | 0.456 | 0.499 | 0.532 | 0.668 | |
| 压缩比/Compression ratio | 19 | ||||||||
| 额定转速(rpm)/Rated speed | 3600 | 3000 | |||||||
| 额定功率(kw)/Rated power | 3.4 | 3.7 | 4.5 | 5.7 | 6.3 | 7.5 | 8.4 | 9.3 | |
| 额定功率(hp)/Rated power | 4.62 | 5.03 | 6.12 | 7.75 | 8.57 | 10.20 | 11.42 | 12.65 | |
| 最大功率( KW)/Max power | 4.05 | 4.00 | 4.95 | 6.27 | 6.93 | 8.25 | 9.24 | 10.23 | |
| 最大功率 (HP)/Max power | 5.51 | 5.44 | 6.73 | 8.53 | 9.42 | 11.22 | 12.57 | 13.91 | |
| 最大扭矩（N.m)/Max torque | 10.37 | 11.29 | 13.73 | 17.39 | 19.22 | 22.88 | 25.63 | 28.37 | |
| 最大扭矩点转速（r/min）/Speed at Max torque point | 2700 | 2700 | 2700 | 2700 | 2700 | 2700 | 2700 | 2700 | |
| 标定点燃油耗（g/kw.h）/Fuel consumption | 280 | ||||||||
| 起动方式/Start mode | 回弹式绳索起动或电起动/Rope start or electric start | 电起动/ Electric start | |||||||
| 燃油牌号/Fuel number | 柴油：0#（夏）-10（冬）Fuel:0#（Summer),-10(Winter) | ||||||||
| 机油牌号/Oil number | SAE10W30(CD级以上) | ||||||||
| 外形尺寸（长*宽*高）（mm）/Overall dimension | 335*392*422 | 385*420*460 | 385*420*460 | 420*440*495 | 420*450*498 | 420*450*498 | 420*450*498 | 420*490*550 | |
| 净重（kg）Net weight | 29 | 35 | 35 | 48 | 52 | 54 | 56 | 60 | |
