系列/SERIES参数/Specification机型/Model24V驻车发电机组/24V vehicle generator set24V驻车发电机组电压（V）Voltage24额定功率(kVA)/Rated frequency3励磁方式/Excitation mode永磁/Permanent magnet油箱容量（L）/Capacity of fuel tank12.5机架类型/Frame type25方管/Round tube动力型号/Power modelCG173F起动方式/St
| 系列/SERIES | 参数/Specification | 机型/Model |
| 24V驻车发电机组/24V vehicle generator set | ||
| 24V驻车发电机组 | 电压（V）Voltage | 24 |
| 额定功率(kVA)/Rated frequency | 3 | |
| 励磁方式/Excitation mode | 永磁/Permanent magnet | |
| 油箱容量（L）/Capacity of fuel tank | 12.5 | |
| 机架类型/Frame type | 25方管/Round tube | |
| 动力型号/Power model | CG173F | |
| 起动方式/Start mode | 回弹式绳索起动或电起动/Rope start or electric start | |
| 动力类别/Power style | 单缸，风冷，四冲程，立式/Single cylinder,Water-cooled,Four stoke,Vertical type | |
| 缸径（mm)/Cylinder bore | 73 | |
| 行程（mm)/Piston stroke | 59 | |
| 排量（L）//Displacement | 0.246937822 | |
| 压缩比/Compression ration | 19 | |
| 转速(rpm)/Speed | 3600 | |
| 发动机功率(kw)/Engine power | 3.4 | |
| 机油容量（L）/Capacity of oil | 0.75 | |
| 标定点燃油耗（g/kw.h）/Fuel consumption | 280 | |
| 燃油牌号/Fuel number | 柴油：0#（夏）-10（冬）Fuel:0#（Summer),-10(Winter) | |
| 机油牌号/Oil number | SAE10W30(CD级以上) | |
| 可选配置/Optional configuration | 大油箱/Big fuel tank,自动控制，一键启停，遥控启动 | |
| 外形尺寸（长*宽*高）（mm）/Overall dimension | 335*392*422 | |
| 净重（kg）/Net weight | 35 |
